FPV SpeedyBee F405 V3 BLS 50A 30×30 Stack
The SpeedyBee F4 V3 with 50A ESC is a powerful and feature-rich flight stack designed for 5-inch and long-range FPV drones. The F4 V3 flight controller features a fast STM32F405 processor, BMI270 gyro, built-in barometer, Blackbox support via microSD card, and Bluetooth for wireless configuration through the SpeedyBee app. The included 50A 4-in-1 ESC supports 3–6S LiPo batteries, delivering reliable power for high-performance motors. With a 30x30 mounting pattern, it fits most standard frames and supports DJI digital video systems. Perfect for freestyle, racing, or cinematic builds, this stack offers performance, reliability, and easy setup in one complete package.
SpeedyBee F405 V3 BLS 60A 30×30 FC&ESC Stack
The SpeedyBee F405 V3 BLS 60A 30×30 FC&ESC Stack is a high-performance flight controller and electronic speed controller combination designed for FPV racing and freestyle drones.
Flight Controller Specifications:
- MCU: STM32F405
- Gyro: BMI270
- USB Port Type: Type-C
- Barometer: Built-in
- OSD Chip: AT7456E
- Bluetooth: Supported (used for flight controller configuration; MSP should be enabled with baud rate 115200 on UART4)
- Power Input: 3S – 6S LiPo
- 5V Output: 9 groups, total current load 2A
- 9V Output: 2 groups, total current load 2A
- 3.3V Output: Up to 500mA current load
- 4.5V Output: Up to 1A current load
- UART: 6 sets (UART1, UART2, UART3, UART4 for Bluetooth, UART5 for ESC telemetry, UART6)
- Mounting: 30.5 x 30.5mm (4mm hole diameter)
- Dimensions: 41.6(L) x 39.4(W) x 7.8(H) mm
- Weight: 9.6g
ESC Specifications:
- Firmware: BLHeli_S J-H-40
- Continuous Current: 60A per motor
- Burst Current: 80A (10 seconds)
- Power Input: 3-6S LiPo
- Dimensions: 45.6(L) x 44(W) x 8(H) mm
- Weight: 23.5g
For more details and purchasing options, visit the official product page: SpeedyBee F405 V4 BLS 60A 30×30 FC&ESC Stack
SpeedyBee F405 V3 BLS 60A 30×30 FC&ESC Stack
The SpeedyBee F405 V3 BLS 60A 30×30 FC&ESC Stack is a high-performance flight controller and electronic speed controller combination designed for FPV racing and freestyle drones.
Flight Controller Specifications:
- MCU: STM32F405
- Gyro: BMI270
- USB Port Type: Type-C
- Barometer: Built-in
- OSD Chip: AT7456E
- Bluetooth: Supported (used for flight controller configuration; MSP should be enabled with baud rate 115200 on UART4)
- Power Input: 3S – 6S LiPo
- 5V Output: 9 groups, total current load 2A
- 9V Output: 2 groups, total current load 2A
- 3.3V Output: Up to 500mA current load
- 4.5V Output: Up to 1A current load
- UART: 6 sets (UART1, UART2, UART3, UART4 for Bluetooth, UART5 for ESC telemetry, UART6)
- Mounting: 30.5 x 30.5mm (4mm hole diameter)
- Dimensions: 41.6(L) x 39.4(W) x 7.8(H) mm
- Weight: 9.6g
ESC Specifications:
- Firmware: BLHeli_S J-H-40
- Continuous Current: 60A per motor
- Burst Current: 80A (10 seconds)
- Power Input: 3-6S LiPo
- Dimensions: 45.6(L) x 44(W) x 8(H) mm
- Weight: 23.5g
For more details and purchasing options, visit the official product page: SpeedyBee F405 V4 BLS 60A 30×30 FC&ESC Stack
